Description
| Specification | |
|---|---|
| Fingerprint Capacity | 6,000 |
| Card Capacity | 10,000 |
| Transactions Capacity | 100,000 |
| User Photos | 3,000 |
| Event Photos | 7,000 |
| Communication | TCP/IP, RS485 (For Slave Reader), USB Host, Wiegand Input / Output, Security Relay Box |
| Hardware | 1.2GHz Dual Core CPU, Memory 128MB RAM / 256MB Flash, SilkID Fingerprint Sensor, 2,4 Inches TFT-LCD Touch Screen, 125KHz EM Reader / IC Card (Optional), Hi-Fi Voice & Indicator, Tamper Switch Alarm, Touch Keypad, 120° Wide Angle Camera |
| Standard Functions | Access Levels / Groups / Holidays , DST / Bell Schedule, Duress Mode, Anti-Passback, Record Query, Custom Wallpaper & Screen Saver |
| Special Functions | Multiple Verification Modes, Alive Finger Detection, Event Snapshot, User Photo(Optional) |
| Access Control Interface | Lock Relay Output, Alarm Output / Auxiliary Input, Exit Button / Door Sensor, Doorbell Output |
| Compatibility | Wiegand Slave Reader, RS485 FP Slave Reader , ZKBioSecurity Software |
| Working Temperature | -10 °C ~ 50 °C |
| Dimensions | 195.5 × 87 × 35 mm. |
| Algorithm | Fingerprint Algorithm ZKFinger v10.0 |
| Power | Operating Voltage 12V DC, Current Draw < 500 mA |
