Description
Specification | |
---|---|
Camera | |
Image Sensor | 2 MP CMOS |
Signal System | PAL/NTSC |
Frame Rate | TVI: 1080p@25fps/30fps CVI: 1080p@25fps/30fps AHD: 1080p@25fps/30fps CVBS: PAL/NTSC |
Resolution | 1920 (H) × 1080 (V) |
Min. illumination | 0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light |
Shutter Time | PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
Lens | 2.8 mm, 3.6 mm, 6 mm Fixed Lens |
Field of View | 2.8 mm, horizontal FOV: 98°, vertical FOV: 51°, diagonal FOV: 115° 3.6 mm, horizontal FOV: 76°, vertical FOV: 41°, diagonal FOV: 90° 6 mm, horizontal FOV: 50°, vertical FOV: 27°, diagonal FOV: 58° |
Lens Mount | M12 |
Light Alarm | Solid Light Alarm (White Light) |
WDR (Wide Dynamic Range) | Digital WDR |
Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° |
General | |
Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation) |
Power Supply | 12 VDC ±25% |
Power Consumption | Max. 4 W |
Protection Level | IP67 |
Material | Main body: Metal, Enclosure: Plastic |
IR Range | Up to 40 m |
Weight | Approx. 355 g (0.78 lb) |
