Description
| Specification | |
|---|---|
| Camera | |
| Image Sensor | 3MP CMOS Image Sensor |
| Effective Pixels | 2052(H)*1536(V) |
| Min. illumination | 0.01 Lux @ (F1.2,AGC ON), 0 Lux with IR |
| Shutter Time | 1/25(1/30)s to 1/50,000s |
| Lens | 2.8mm, 3.6mm, 6mm, 8mm, 12mm, 16mm optional |
| Lens Mount | M12 |
| Lens | 3.6 mm, 6 mm, 8 mm, 12 mm fixed lens |
| Day & Night | ICR |
| Angle Adjustment | Pan: 0°- 360°; Tilt:0°- 90°; Rotate: 0°- 360° |
| Synchronization | Internal synchronization |
| Video Frame Rate | 1920×1536@18fps |
| HD Video Output | 1 Analog HD output |
| General | |
| Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation) |
| Power Supply | 12 VDC ±15% |
| Power Consumption | Max. 5 W |
| Protection Level | IP66 |
| Communication | Up the coax, Protocol: HIKVISION-C (TVI output) |
| IR Range | Up to 40 m |
| Weight | Approx. 680g (1.5lb) |
