Description
| Specification | |
|---|---|
| Camera | |
| Image Sensor | 2.0 megapixel progressive scan CMOS |
| Signal System | PAL/NTSC |
| Frame Rate | TVI: 1080p @ 25 fps/30 fps CVI: 1080p @ 25 fps/30 fps AHD: 1080p @ 25 fps/30 fps CVBS: PAL/NTSC |
| Resolution | 1920 (H) × 1080 (V) |
| Min. illumination | Color:0.005 Lux @ (F1.8, AGC ON), 0 Lux with white IR |
| Shutter Time | PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
| Lens | 2.8 mm to 12 mm motorized vari-focal lens |
| Slow Shutter | Max. 16 times |
| Lens Mount | M12 |
| Horizontal Field of View | 103°to 32.1° |
| Day & Night | ICR |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360° |
| General | |
| Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation) |
| Power Supply | 12 VDC ± 25%/PoC.at |
| Power Consumption | Max. 8.2 W |
| Protection Level | IP67 |
| Material | Metal |
| IR Range | Up to 40 m |
| Weight | Approx. 900 g (1.98 lb.) |
