Description
| Specification | |
|---|---|
| Camera | |
| Image Sensor | 2MP CMOS Image Sensor |
| Signal System | PAL/NTSC |
| Frame Rate | PAL: 1080p@25fps NTSC: 1080p@30fps |
| Resolution | 1920 (H) × 1080 (V) |
| Min. illumination | 0.01 Lux @(F1.2, AGC ON), 0 Lux with IR |
| Shutter Time | 1/25 (1/30) s to 1/50,000 s |
| Lens | 3.6 mm, 6 mm, 8 mm, 12 mm fixed lens |
| Horizontal Field of View | 82.2 ° (3.6 mm), 54 ° (6 mm), 37.7 ° (8 mm), 24.2° (12 mm) |
| Lens Mount | M12 |
| Synchronization | Internal synchronization |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360° |
| General | |
| Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation) |
| Power Supply | 12 VDC ±15% |
| Power Consumption | Max. 6 W |
| Protection Level | IP66 |
| Material | Front cover: Metal Main body: Plastic Bracket: Metal |
| IR Range | Up to 80 m |
| Weight | Approx. 430 g (0.95 lb.) |
