Description
| Specification | |
|---|---|
| Camera Feature | |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Effective Pixels | 4MP |
| IR Distance | Up to 30 m IR range |
| Lens | |
| Type | 2.8 mm/4 mm/6 mm fixed lens |
| 2.8 mm: 2.8 mm, horizontal FOV 100°, vertical FOV 55°, diagonal FOV 117° | |
| 4 mm: 4 mm horizontal FOV 77°, vertical FOV 42°, diagonal FOV 88° | |
| 6 mm: 6 mm horizontal FOV 51°, vertical FOV 28°, diagonal FOV 58° | |
| Aperture | F2.0 |
| Angle of View | horizontal FOV 78.7°, vertical FOV 43.1°, diagonal FOV 92.3° |
| Physical Specification | |
| Dimension | 177.6 mm × 66.2 mm × 67.8 mm |
| Weight | Approx. 280 g (0.62 lb.) |
| Power | PoE (Power over Ethernet) |
| Power Supply: 12 VDC ± 25%, PoE (802.3af Class3) | |
| Power Consumption: | |
| 12 VDC, 0.4 A, Max: 5 W | |
| PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.13 A, Max: 7 W | |
| Interface | Φ 5.5 mm coaxial power plug |
| 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
| Others | On-Board Storage: Built-in memory card slot, support microSD card, up to 256 GB |
| Built-In Microphone: Yes | |
| Hardware Reset: Yes | |
