Description
| Specification | |
|---|---|
| System | |
| Main Processor | Industrial-grade processor |
| Operating System | Embedded LINUX |
| Audio and Video | |
| IP Camera Input | Up to 32 channels of IPC access |
| 32 channels (analog channels are converted to IP channels) | |
| incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps | |
| Two-Way Talk | Yes (share the same audio input with the first channel) |
| Display | |
| Interface | 1 HDMI, 1 VGA, 1 TV |
| Resolution | VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
| HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 | |
| Multi-Screen Display | 1/4/8/9/16/25/36 |
| OSD | Camera title, Time, Video loss, Camera lock, Motion |
| detection, Recording | |
| Recording | |
| Compression | Video Compression: AI Coding; Smart H.265+; H.265; Smart H.264+; H.264 |
| Audio Compression: G.711a; G.711u; PCM | |
| Record Rate | Main stream: 5M-N@(1fps–10fps); 4M-N,1080p@(1fps–15fps); 1080N, 720p, 960H, D1,CIF@(1fps–25/30fps) |
| Sub stream: D1, CIF@(1fps–15fps) | |
| Bit Rate | 32 kbps–6144 kbps |
| Record Mode | General, motion detection; intelligent; alarm; POS |
| Playback And Backup | |
| Playback Function | Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) |
| Backup Mode | USB device and network |
| Network | |
| Ethernet Port | 1 (10/100/1000 Mbps Ethernet port, RJ-45) |
| Storage | |
| Internal HDD | 2 SATA ports, up to 16TB capacity for each disk. The maximum HDD capacity varies with environment temperature. |
| Auxiliary Interface | |
| USB | 2 (1 front USB 2.0 port, 1 rear USB 3.0 port) |
| RS485 | 1 port, for PTZ control |
| Power | |
| Power Supply | DC 12V, 5A |
| Power Consumption | <16 W (without HDD) |
| Component Environment | |
| Operational Conditions | –10 °C to +55 °C (14 °F to +131 °F) |
| Construction | |
| Dimensions | 375.0 mm × 289.4 mm × 53.0 mm (14.76'' × 11.40'' × 2.09'') (W × D × H) |
| Net Weight | 1.90 kg (4.20 lb) |
| Gross Weight | 3.20 kg (7.00 lb) |
| Warranty | |
| Manufacturing Warranty | 1 year |
