Description
| Specification | |
|---|---|
| System | |
| Main Processor | Embedded Processor |
| Operating System | Embedded LINUX |
| Audio and Video | |
| IP Camera Input | 4+2/8+4/16+8 Channel, each channel up to 5MP |
| Two-Way Talk | Reuse audio in/out, RCA |
| Display | |
| Interface | 1 HDMI ,1 VGA |
| Resolution | 1920×1080, 1280×1024, 1280×720, 1024×768 |
| Multi-Screen Display | When IP extension mode not enabled: |
| 4CH: 1/4 | |
| 8CH: 1/4/8/9 | |
| 16CH: 1/4/8/9/16 | |
| When IP extension mode enabled: | |
| 4CH: 1/4/6 | |
| 8CH: 1/4/8/9/16 | |
| 16CH: 1/4/8/9/16/25 | |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Recording | |
| Compression | H.264+/H.264 |
| Resolution | 4M-N, 1080P, 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF |
| Record Rate | Main stream: 4M-N/1080P(1~15fps); 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF(1~25/30fps) |
| Sub steram: D1/CIF/QCIF(1~15fps) | |
| Bit Rate | 1Kbps ~ 6144Kbps Per Channel |
| Record Mode | Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Record Interval | 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Video Detection And Alarm | |
| Trigger Event | Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis |
| Alarm Input | N/A |
| Relay Output | N/A |
| Playback And Backup | |
| Sync Playback | 4CH: 1/4 |
| 8CH: 1/4/9 | |
| 16CH: 1/4/9/16 | |
| Search Mode | Time /Date, Alarm, MD and Exact Search (accurate to second) |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode | USB Device/Network |
| Third Party Support | |
| Third Party Support | Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
| Network | |
| Interface | 4/8CH: 1 RJ-45 Port (100M) |
| 16CH: 1 RJ-45 Port (1000M) | |
| Network Function | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Support Dahua IP camera, DVR, NVS, etc.) |
| Maximum User Access | 128 users |
| Smart Phone | iPhone, iPad, Android |
| Interoperability | ONVIF 2.42, CGI Conformant |
| Storage | |
| Internal HDD | 2 SATA Port, up to 8TB capacity |
| eSATA | N/A |
| Auxiliary Interface | |
| USB | 4/8CH:2 USB 2.0 |
| 16CH:1 USB 2.0 , 1 USB 3.0 | |
| RS232 | N/A |
| RS485 | 1 Port, for PTZ Control |
| Power | |
| Power Supply | DC12V/5A |
| Power Consumption | <15W (Without HDD) |
| Component Environment | |
| Operational Conditions | -10°C ~ +55°C (+14°F ~ +131°F), 0~ 90% RH |
| Storage Conditions | -20°C ~ +70°C (-4°F ~ +158°F) , 0~ 90% RH |
| Construction | |
| Dimensions | 1U, 375mm×287mm×53mm (14.8" x 11.3" x 2.1") |
| Net Weight | 2.35kg (5.2 lb) (without HDD) |
| Gross Weight | 3.2kg (7.05lb) |
| Warranty | |
| Manufacturing Warranty | 1 year |
