Description
| System | |
|---|---|
| Main Processor | Embedded Processor |
| Operating System | Embedded LINUX |
| Audio and Video | |
| IP Camera Input | 4+1 channels, each channel up to 2MP |
| Two-Way Talk | Reuse audio in/out, RCA |
| Display | |
| Interface | 1 HDMI; 1 VGA |
| Resolution | 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Multi-Screen Display | When IP extension mode not enabled: 1/4 |
| When IP extension mode enabled: 1/4/6 | |
| OSD | Camera title; Time; Video loss; Camera lock; Motion detection; Recording |
| Recording | |
| Compression | AI Coding/H.265+/H.265/H.264+/H.264 |
| Resolution | 1080N; 720p; 960H; D1; CIF |
| Record Rate | Main Stream: All channels 1080N/720P/960H/D1/CIF/(1~25/30fps) |
| Sub stream: CIF (1~15 fps) | |
| Bit Rate | 32 kbps–4096 kbps per channel |
| Record Mode | Manual; Schedule (General, Continuous); MD (Video |
| detection: Motion Detection, Video Loss, Tampering); | |
| Alarm; Stop | |
| Record Interval | 1 min– 60 min (default: 60 min), Pre-record: 1 s–30 s, Post-record: 10 s–300 s |
| Video Detection And Alarm | |
| Trigger Event | Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis |
| Alarm Input | N/A |
| Relay Output | N/A |
| Playback And Backup | |
| Sync Playback | 4-Jan |
| Search Mode | Time/Date; Alarm; MD and Exact Search (accurate to second) |
| Playback Function | Play; Pause; Stop; Rewind; Fast play; Slow Play; Next File; Previous File; Next Camera; Previous Camera; Full Screen; Repeat; Shuffle; Backup Selection; Digital Zoom |
| Backup Mode | USB Device/Network |
| Third Party Support | |
| Third Party Support | Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
| Network | |
| Interface | 1 RJ-45 Port (100 Mbps) |
| Network Function | HTTP; HTTPS; TCP/IP; IPv4/IPv6; 3G/4G; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; P2P; IP Search (Supports Dahua IP camera, DVR, NVS, etc.) |
| Maximum User Access | 128 users |
| Smart Phone | iPhone; iPad; Android |
| Interoperability | ONVIF 16.12, CGI Conformant |
| Storage | |
| Internal HDD | 1 SATA port, up to 6 TB capacity |
| eSATA | N/A |
| System | |
| Main Processor | Embedded Processor |
| Operating System | Embedded LINUX |
| Audio and Video | |
| IP Camera Input | 4+1 channels, each channel up to 2MP |
| Two-Way Talk | Reuse audio in/out, RCA |
| Display | |
| Interface | 2 HDMI; 1 VGA |
| Resolution | 1921 × 1080, 1280 × 1024, 1280 × 720 |
| Multi-Screen Display | When IP extension mode not enabled: 1/5 |
| When IP extension mode enabled: 1/4/7 | |
| OSD | Camera title; Time; Video loss; Camera lock; Motion detection; Recording |
| Recording | |
| Compression | AI Coding/H.265+/H.265/H.264+/H.265 |
| Resolution | 1080N; 720p; 960H; D1; CIF |
| Record Rate | Main Stream: All channels 1080N/720P/960H/D1/CIF/(1~25/30fps) |
| Sub stream: CIF (1~15 fps) | |
